Rated Frequency |
50/60HZ |
|
Rated Voltage |
220/380V |
Generator |
Rated Current |
18.3A/ 20.8/41.7A |
|
Rated Power |
5KW |
|
DC Output |
12V/8.3A |
|
Power Factor |
1 |
|
Model |
186F |
|
Type |
Single-cylinder,
4-stroke, air-cooled |
|
Combustion System |
Direct injection
combustion |
|
Bore x Stroke |
86 x 70mm |
Engine |
Piston Displacement |
0.406L |
|
Rated Power |
6.6KW |
|
Lube Capacity |
1.65L |
|
Lube Oil Brand |
SAE 10W30 (above CC
grade) |
|
Fuel Tank Capacity |
25L |
|
Starting System |
Electric Starter |
|
Structure |
Silent Type |
|
Power of Lamps |
4 x 400 W |
|
Light Capacity |
4 x 25000 LUMEN |
|
Type of Lamp |
Metal Halide Lamp |
|
Light Coverage |
5 to 7 ACRES |
|
Connection Protection
Index |
IP54 |
Light & Frame |
Woking Temperature |
Less Than 85 degrees |
|
Lifetime of Lamp |
5000 HOURS |
|
Max. Extension of
Mast |
7m |
|
Rasing and Falling
Mast |
Mechanical Winch or
Electric Button |
|
Turning Angle |
360 degree |
|
Tire Diameter |
52 CM |
|
Anti-wind Power |
Less Than 10 |
|
Slope |
Less Than 10 |
